Helix Hydro Plastic Hydraulic Control Valves
The major development of a market garden row-crop property in northern Victoria focused on installing Helix...
Maximum Injection
1.5-24 l/hr
Pressure Rating
5-16 Bar
Adjustment Method
Digital
Stroke/min
50-164
Operating Mode
Digital control, proportional pulse control, batch dosing and manual flow control
Turn Down Ratio
1:3000
| Cat. No. | Max Injection L/hr | Max Injection Pressure Bar |
|---|---|---|
| DOSMART1.5 | 1.5 | 16 |
| DOSMART4 | 4 | 12 |
| DOSMART8 | 8 | 8 |
| DOSMART12 | 12 | 7 |
| DOSMART24 | 24 | 5 |
Suitable for a wide range of industry applications.
Advanced dosing control for accurate and efficient automatic regulation. Suction capacity up to 6m.
Turndown ratio of 1:3000.
Remote activation, flow calibration, high suction capacity.
| Specification | Value |
|---|---|
| Maximum Injection | 1.5-24 l/hr |
| Pressure Rating | 5-16 Bar |
| Adjustment Method | Digital |
| Turn Down Ratio | 1:3000 |
| Ingress Protection | IP65 |
| Stroke/min | 50-162 |
| Operating Mode | Digital control panel, proportional pulse control, batch dosing and manual flow control |
| Dimension | Value |
|---|---|
| Maximum Injection | 1.5-24 l/hr |
| Pressure Rating | 5-16 Bar |
Agriculture & Irrigation
Cooling Towers
Town Water Supply
