Maximum Injection
6.5-1254 l/ph
Maximum Injection Pressure
5-15 Bar
| Cat. No. | Max Injection L/hr | Max Injection Pressure kPa | |
|---|---|---|---|
| DTEC-AC2-10D | DOSTEC AC 40 | 6.5 – 9.5 | 1500 |
| DTEC-AC2-50D | 38 – 53 | 1500 | |
| DTEC-AC2-100D | 83 – 111 | 1000 | |
| DTEC-AC2-200D | 173 – 209 | 800 | |
| DTEC-AC2-250D | 251 – 284 | 500 | |
| DTEC-AC2-340D | 301 – 342 | 500 | |
| DTEC-AC3-480D | DOSTEC AC 50 | 373 – 481 | 1000 |
| DTEC-AC3-620D | 498 – 624 | 1000 | |
| DTEC-AC3-820D | 624 – 822 | 700 | |
| DTEC-AC3-1200D | 1044 – 1254 | 500 |
Suitable for a wide range of chemicals.
Minimal wastage. Maximum accuracy.
Remote control allows for efficient automatic regulation.
Applications include, water treatment, industrial processors, agriculture, pulp and paper and chemical treatment.
| Specification | Value |
|---|---|
| Maximum Injection | 6.5-1254 l/ph |
| Maximum Injection Pressure | 5-15 Bar |
